Scale remover in Cooling tower
The Electro Life EL-10A-1 is our self-developed product that utilizes electrolysis technology to effectively eliminate scale build-up in cooling towers and circulating water systems (Patents 4214139 and 4644677).
It offers a stronger removal effect compared to chemical treatments, magnetic methods, and mild electrolysis techniques. This is designed to maintain the efficiency of heat exchangers, significantly contributing to energy conservation and CO₂ emission reduction.
Furthermore, the device is safe to use, as it does not cause corrosion or damage to pipes.
What is Electro Life？
Electro Life is an innovation that utilizes unique electrolysis technology to powerfully eliminate scales attached to the recirculating cooling water system such as cooling towers and chillers. It is also capable of preventing scales from building up again.
Thanks to scale removal by Electro Life, cooling towers and chillers can enjoy significantly enhanced heat transfer efficiency. As a result of this, costs of electricity and water bills can be greatly reduced.
Furthermore, Electro Life doesn’t need water treatment chemicals. For this reason, many other costs such as those for chemical feeding and water softeners can be saved. There’s no need for water treatment as well.
When the recirculating cooling water system becomes maintenance-free, cleaning costs will be reduced significantly, and there’s no need to suspend the equipment’s operation.
Reduced heat transfer efficiency due to scale build-ups
- Energy Loss → Increased electricity consumption（More CO2).
- Unstable operation of the equipment → Increased defective products、suspended operation, reduced production efficiency due to maintenance.
- Suspension of the equipment’s operation due to pipe cleaning → Acid wash method can be detrimental to the equipment.
Product Specifications
DIMENSIONS
D 350mm / W 730mm / Ｈ 1200mm
INPUT POWER SUPPLY
Single-phase AC 100 – 240V, 50/60Hz
TREATMENT METHOD
Electrolytic method (Maximum 10A, arbitrary current preset system)
APPLICABLE COOLING TOWER SIZE
150 – 300 RT (Depending on usage environment)
With Electro Life, you can enjoy a maintenance-free solution that can also save up to 20-40% on your electric bill!
Operational Principle
